Create 450/600 Bridge Saw Cutting Machine With CNC Control And Safety Features

Name: Create 450600 Bridge Saw Cutting Machine With CNC Control And Safety Features
Brand: Xianda Machinery
Price: 1 USD

Create 450/600 Bridge Saw Cutting Machine With CNC Control And Safety Features Manufactures

Brand Name : Xianda Machinery

Model Number : Create 450/600

Place Of Origin : Jinjiang,Fujian,China

Certification : API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF

MOQ : 1

Price : To Be Negotiable

Packaging Details : Plastic Package, Suitable For Sea Transportation

Delivery Time : 1 Month

Payment Terms : L/C， T/T， D/P， Western Union ，Paypal ，Money Gram， Others

Supply Ability : 1000 Sets/Year

Brand : Xianda Machinery

Control : CNC

Max Lifting Travel : 500mm

Hs Code : 84641090

Gross Weight : 8000kg

Advantage : Fast Cutting Speed,High Sharpness

Origin : Jinjiang, Fujian, China

Warranty : 1 Year

Place of Origin : Jinjiang, Fujian, China

Contact Now

Create 450/600 Bridge Saw Cutting Machine with CNC Control and Safety Features

1. Absolute Positioning Accuracy

The integrated absolute-value encoder maintains positional data during power outages, eliminating re-homing procedures.

2. Precision Engineering

• Linear guideways: ±0.02mm repeatability
• Ball screw transmission: <0.01mm backlash
• Oil-bath lubrication system extends component lifespan by 40%

3. Versatile Processing Capabilities

• Edge profiling (ogee, bullnose, waterfall)
• 3D contour cutting
• Sink cutouts & complex geometric patterns

Parameter	Unit	Create 450	Create 600
Blade diameter range	mm	350-450	350-600
Max processing size	mm	32002000120	34002000180
Lifting stroke	mm	300	500
Worktable size	mm	3200*2000	3400*2000
Table tilting degree	°	0-85°	0-85°
Head rotating degree	°	0-360°	0-360°
Air speed	m/min	15	15
Repeated accuracy of positioning	mm	0.1mm/1000	0.1mm/1000
Main motor	kw	18.5(Permanent magnetic system synchronous motor)	22(Permanent magnetic system synchronous motor)
Gross power	kw	26	30
Water consumption	m³/h	3	3
Outline dimension	mm	560036003500	580036503900
Head tilting degree	°	0-90°	0-90°
Gross weight	kg	6000	7500

Create 450/600 Bridge Saw Cutting Machine With CNC Control And Safety Features

Support and Services

- Installation guidance and setup assistance for the machine.
- Troubleshooting support for any technical issues that may arise.
- Training sessions for operators on how to use the machine efficiently.
- Regular maintenance services to ensure optimal performance and longevity of the equipment.

Packing and Shipping

Product Packaging
The Machine is carefully packed in a sturdy wooden crate to ensure safe transportation. The machine is securely fixed within the crate to prevent any damage during shipping.
Shipping
We ship the Machine worldwide using trusted shipping services. The machine is shipped in a protective wooden crate to safeguard it from any potential damage during transit. Customers will receive tracking information once the order is shipped to monitor the delivery status.
